Since 1883, Heckscher & Company has supplied the finest quality German piano wire to piano factories, workshops & technicians, as well to the creative arts and light and heavy industry.

Gauges 0.19mm - 0.55mm available in 100g Coils

MWG MM Inches Nearest SWG Breaking Strain Metres Per Coil
000 .19 .007 36 19 LBS 407M
00 .21 .008 35 19 LBS
357M
0 .23 .009 34 19 LBS 297M
1 .25 .010 33 29 LBS 251M
2 .27 .011 32 29 LBS 208M
3 .30 .012 31 42 LBS 175M
4 .33 .013 30 42 LBS 149M
5 .35 .014 29 57 LBS 128M
6 .40 .016 28 74 LBS 98M
7 .45 .018 27 94 LBS 77M
8 .50 .020 25 118 LBS 62M
9 .55 .022
24 152 LBS 52M

Gauges 0.625mm - 1.6mm available in 500g Coils

MWG MM Inches Nearest SWG Breaking Strain Metres Per Coil
10 .625 .024 23 179 LBS 219M
11 .675 .026 22 201 LBS 187M
12 .725 .028 22 223 LBS 160M
12.5 .75 .029 22 238 LBS 148M
13 .775 .030 21 251 LBS 136M
13.5 .80 .031 21 267 LBS 128M
14 .825 .032 21 282 LBS 119M
14.5 .85 .033 21 298 LBS 113M
15 .875 .034 20 313 LBS 106M
15.5 .90 .035 20 328 LBS 101M
16 .925 .036 20 346 LBS 94M
16.5 .95 .037 20 362 LBS 91M
17 .975 .038 20 377 LBS 86M
17.5 1.0 .039 19 395 LBS 81M
18 1.025 .040 19 412 LBS 78M
18.5 1.05 .041 19 430 LBS 74M
19 1.075 .042 19 448 LBS 70M
19.5 1.1 .043 19 465 LBS 67M
20 1.125 .044 19 481 LBS 64M
20.5 1.15 .045 18 498 LBS 62M
21 1.175 .046 18 516 LBS 59M
21.5 1.2 .047 18 531 LBS 57M
22 1.225 .048 18 551 LBS 54M
22.5 1.25 .049 18 569 LBS 51M
23 1.3 .051 18 608 LBS 49M
24 1.4 .055 17 653 LBS 42M
25 1.5 .059 17 697 LBS 37M
26 1.6 .069 16 745 LBS 32M
